Fractal Design Meshify C TG Atx Casing Light Tint

Specifications

3.5" or 2.5" Drive capacity
2
Dedicated 2.5" drive capacity
3
Expansion slots
7
Front ports
2x USB 3.0, Audio I/O, Power button, Reset button
Total fan mounts
7
Front fan
3x 120 mm or 2x 140 mm (1x Dynamic X2 GP-12 included)
Top fan
2x 120/140 mm
Rear fan
1x 120 mm (1x Dynamic X2 GP-12 included)
Bottom fan
1x 120 mm
Dust filters
Bottom fan + PSU, Front fans, Top fans
Cable routing grommets
Yes
Fixed velcro straps
Yes
Captive thumbscrews
Both side panels, SSD brackets
Left side panel
Tempered Glass (3mm Thick)
Right side panel
Steel

Compatibility

Power supply type
ATX
Motherboard compatibility
ATX, mATX, ITX
Front radiator
120/240/360 mm, 140/280 mm
Top radiator
120/240 mm (max component height on motherboard 40 mm)
Rear radiator
120 mm (max width 125 mm)
PSU max length
175 mm
GPU max length
315 mm with front fan mounted
CPU cooler max height
170 mm
Cable routing space
15-35 mm

Dimensions

Case dimensions (LxWxH)
395 x 212 x 440 mm
Case dimensions - with feet/protrusions/screws
413 x 217 x 453 mm
Net weight
6.45 kg
Package dimensions (LxWxH)
542 x 305 x 493 mm
Package weight
7.81 kg

Other

Package contents
Meshify C TG computer case, User manual, Accessory box, Top filter
EAN
7340172700074
UPC
84327610074
Product code (Black)
FD-CA-MESH-C-BKO-TGL
Product code (White)
FD-CA-MESH-C-WT-TGC
